̶ 24 ̶
6-10. Measuring h
FE
(DC Current Amplification Factor)
# CAUTION:
With the germanium transistor, the leakage current flows into
the collector side, causing that much error in leakage current
measurements. Therefore, obtain a true value of leakage current
by deducting a h
FE
value equivalent to the leakage current from the
measured value.
⑴ The following will explain about the principle of h
FE
measurements.
As shown in Fig. 7, the collector and emitter of a transistor are
connected to the multimeter. When a resistor R of a certain
resistance value (approx. 24kΩ) is connected across the N (−COM)
terminal of the instrument and the base of the transistor, base-
terminal current I
B
, determined by R (approx. 24kΩ), flows and current
I
C
, multiplied by h
FE
, also flows into the collector of the transistor,
resulting in the increase of DC current and thus causing the meter
indication to change notably.
Theoretically, the h
FE
(=l
C
/l
B
) of a transistor (DC current amplification
factor) can be measured by plotting the amount of the current change
on a separate h
FE
scale.
The h
FE
scale for Model 1109 is marked for the 24kΩ R (approx.
100μA base current at 3V LV).
Fig. 7
(E) EMITTER
(C) COLLECTOR
(B) BASE
I
ECO
＋(I
B
×h
FE
)
＝I
C
h
FE
＝−
I
C
I
B
I
B
P(+)
R(24kΩ) (B)
(E)
(C) N(-COM)
X10(h
FE
)
h
FE
