LS 4100/LS 4150 03/2002
4
1.3 Technical data
Housing
Housing material stainless steel 1.4571/ 316Ti
Protection IP 67
Torque on the hexagon 80 Nm
Plug connection 4-pole plug
with status indication (illuminated ring)
Terminals max. 1 x 1.5 mm
2
Process connection
LS 4100
- thread G 1 A or 1" NPT
- material 1.4571 (316Ti)
LS 4150
- thread G 1 A or 1" NPT
- cone DN 25
- Tri-Clamp 1" or 2"
- bolting DN 40 or DN 50
- Tuchenhagen Varivent
- hygienic connection with compression nut F40 PN 25
- hygienic connection with tension flange DN 32 PN 25
Tuning fork
Material 1.4581 (stainless steel)
Weight
Total weight
approx. 0.4 kg
Ambient conditions
Ambient temperature on the housing -40…+70°C
Storage and transport temperature -40…+70°C
Product temperature -40…+150°C
Ambient temperature on
the housing
Operating pressure
max. 40 bar
Product
Viscosity
0.2…10.000 mPa s
Density >
0.6 g/cm
3
P ro d u ct
te m p e ra tu re
