14
3 OPERATION OF THE SIGNAL CONVERTER
The IFM 4080 K / i-EEx compact flowmeters are always equipped with magnet sensors. In
that way is possible to change the settings of the converter with aid of the magnet-bar
without the necessity to open the flameproof converter housing in the hazardous area.
For the program functions and settings of the converter the standard Installation and
operating instructions have to be consulted. It must be noted that - depending on the
IFC090 i-EEx version installed - not all output/input functions are available.
Following menus do not apply for the IFC090 i-EEx versions Ex-i2 and Ex-i3:
(see also section 4.4. "Table of settable Functions" in the of the standard "Installation and
operating instructions" of the IFC090 K/F signal converter)
•
1.01 à VALUE P
•
1.06 Output/input B1
•
1.07 Output/input B2
•
1.06 PULS B1
•
1.06 STATUS B1
•
1.07 STATUS B2
•
1.06 CONTROL B1
•
1.07 CONTROL B2
•
3.02 à VALUE P
•
3.07 HARDWARE
Fct. Text Description and settings
1.00 OPERATION Operations menu
1.01 FULL SCALE ...
à VALUE P
1.06 Output/Input B1
1.07 Output/Input B2
1.06 PULS B1
1.06
1.07 STATUS B1
STATUS B2
1.06
1.07 CONTROL B1
CONTROL B2
3.00 INSTALL. Installation menu
3.02 FLOWMETER ...
à VALUE P
3.07 HARDWARE
As a consequence, the chapters included in the standard Installations and operating
instructions, giving detailed descriptions of these menus, must be skipped.
4 SERVICE
See section 8 or contact your (local) Krohne sales representative for the ordering information
of spare parts or replacements of IFC 090…-EEx electronics units and/or power fuses.
