OPTISWITCH 4000 C, high temperature version
~88mm (3
15
/ 32
")
~101mm (3
31
/ 32
")
L
40mm
(1
37
/ 64
")
13mm ( 33
/ 64
")
ø21,3mm
( 27 /
32
")
ø31,7mm
(1 1 /
4
")
G 3 /
4
A, 3 /
4
"NPT
G1A, 1"NPT
32
1 2
3
L
Fig. 14: OPTISWITCH 4000 C, high temperature version
1 Thread G¾ A, G1 A, ¾ NPT or 1 NPT (valve plug DIN 43650)
2 Tri-Clamp (valve plug DIN 43650)
3 Switching point
L Length with G¾ A, ¾ NPT: 66 mm (2.6 in)
L Length with G1 A, 1 NPT: 69 mm (2.7 in)
L Length with Tri-Clamp: 53 mm (2.1 in)
L Threaded version - Length with switching point like VEGASWING 71 or 81 = L + 48 mm (1.9 in)
L Tri-Clamp - Length with switching point like VEGASWING 71 or 81 = L + 55 mm (2.17 in)
Supplement
OPTISWITCH 4000 C - with contactless electronic switch 29
