8
APPENDIX
28
OPTISWITCH 6500 C
www.krohne.com 01/2014 - 4000649104 - MA OPTISWITCH 6500 R04 en
8.1 Order code
Order code for configuration tool (incl. interface unit + USB cable + CD with driver +
alligator clips + M12 connection cable)
1 OPTISWITCH 6500 C, with IP67 (equivalent to NEMA4X), stainless steel housing -
FDA compliant materials
The use of a VGP7 process connections is required for 3A approved switches.
Process connection Process connection Process connection Process connection
For hygienic use in combination with VGP7 process connections For hygienic use in combination with VGP7 process connections For hygienic use in combination with VGP7 process connections For hygienic use in combination with VGP7 process connections
1 G½ - standard sensor length 18 mm / 0.7" (for use with hygienic process
connections)
2 DN38 hygienic connection incl. EPDM "O"-ring, 3A certified - insertion length
of 18 mm
For non-hygienic use For non-hygienic use For non-hygienic use For non-hygienic use
3 G½ - with rigid extended sensor 100 mm / 3.9" (sliding connection)
4 G½ - with rigid extended sensor 250 mm / 9.8" (sliding connection)
Electrical connection Electrical connection Electrical connection Electrical connection
1 M16 - polyamid cable gland included
2 M16 - brass cable gland included
3 M12 - 4-pin connector plug
Approvals Approvals Approvals Approvals
0 Without
1 Certified acc. to 3A, G½, DN 38 in combination with hygienic adapter
VGP7
Output configuration Output configuration Output configuration Output configuration
0 Standard
1 Customer settings - based on data from an installed device.
"% of triggering, damping, hysteresis, output mode" to be
specified separately.
VGP9 VGP9 VGP9 VGP9 4 1 0 0 0 Order code
XGP9 XGP9 XGP9 XGP9 0 0 0 0 1 0 Order code
