Page 18
4
ELECTRICAL CONNECTIONS
18
OPTISWITCH 6500 C
www.krohne.com
01/2014 - 4000649104 - MA OPTISWITCH 6500 R04 en
DANGER!
Disconnect the power supply before connecting the configuration tool to the switch!
Figure 4-1: Electrical connection of configuration tool
a = red alligator clip
b = black alligator clip
INFORMATION!
Ambient temperature range is 0...+50
°
C / +32...+122
°
F.
DANGER!
The configuration tool cannot be connected to the OPTISWITCH 6500 C within the hazardous
area. For programming, remove the device out of this area.
