2.6 Mounting of the compact version
2.7 Mounting of the wall housing, remote version
1 Prepare the holes with the aid of the mounting plate.
2 Fasten the device securely to the wall with the mounting plate.
INFORMATION!
The signal converter is mounted directly on the measuring sensor. For installation of the
flowmeter, please observe the instructions in the supplied product documentation for the
measuring sensor.
INFORMATION!
Assembly materials and tools are not part of the delivery. Use the assembly materials and tools
in compliance with the applicable occupational health and safety directives.
Figure 2-2: Mounting of the wall housing
