1. Connecting the Handheld LPC with a Computer
This Software Operation Manual describes the method of connecting the Handheld Laser Particle Counter
(LPC) with a personal computer (hereinafter “computer”) by using a communication cable (model 3887-08)
and performing a remote control measurement.
The measurement data collected by remote control is stored in a format of Microsoft Office Excel (*.CSV)
document.
1.1 Handheld LPC Setting
To perform a remote control measurement, the Handheld LPC must be set to Remote Mode.
The following describes the procedure for setting the instrument to Remote Mode.
Display Screen
Key
Operation
Description
POWER Turn on the power by pressing the POWER key.
ENTER
Proceed to the screen by pressing the
ENTER key.
▲▼
ENTER
Select “5. REMOTE” by using the ▲▼ key, and
press the ENTER key.
▲▼
ENTER
Switch “NO” to “OK” by using the ▲▼ key, and
press the ENTER key.
Use the Utility Software to confirm the connection
with the instrument.
Note: Time and data displayed on the instrument
screen during remote control measurement are for
reference only. They are different from the actual
data transferred to the computer.
[Caution]
When communication with the computer cannot be made, please confirm the followings.
1) Confirm that the ID number of the instrument is set to “00”.
[MENU] → [3.OPTIONS] → [3.UTILTIES] → [3.ID 00 (MAX31)]
2) Confirm that the communication mode of the instrument is set to “RS232C”.
[MENU] → [3.OPTIONS] → [3.UTILTIES] → [4.COMMUNICATION]
(If setting is “RS485”, change it to “RS232C”.)
REMOTE
15:25
0.3 0.00E+0/cf
0.5 0.00E+0/cf
5.0 0.00E+0/cf
1.REPEAT 4.CALC
2.SINGLE 5.REMOTE
3.CONT 6.ISO>C4
Fig. 1-1 Instrument Setting
REMOTE 0.3/0.5/5.0µm
LOC. 192
OK
