15
Specification of Main Unit
Product Name Airflow Transducer (with / without Display)
Model 6332 / 6332D
Measuring Object Clean Airflow
Measuring Range Maximum range 0.1 ~ 50 m/s (Depending on the measurement range of the probe*)
Measuring Accuracy ± (3% of reading + 0.1) m/s
0.1-4.99m/s 5.00-9.99m/s 10.0-24.9m/s 25.0-50.0m/s
5～40℃ ± 0.25m/s ± 0.50m/s ± 1.25m/s ± 2.50m/s
Temperature
Compensation Range
40～80℃ ± 0.35m/s ± 0.70m/s ± 1.75m/s ± 3.50m/s
Output
To select either current or voltage output (setting made with the DIP switch).
Current output: DC 4~20mA (Max. load resistance: 250Ω)
Voltage output: DC 0~5V
Setting of
Output Range
To be selected from the followings (setting made with the rotary switch).
0~2, 0~5, 0~10, 0~25, or 0~50 m/s
Display (Optional)
Number of digits and range of value to be displayed change in accordance with the
setting of the output range.
When setting of output range: 0~2, 0~5, 0~10 m/s → Display Resolution: 0.01m/s
When setting of output range: 0~25, 0~50 m/s → Display Resolution: 0.1m/s
Power Supply DC 12~24V
Power Consumption
(Reference Value)
Approx. 2.0W (Under the following conditions - power supply: 12V, air velocity:
approx. 10m/s, using a unit with a display with probe model 0965-03.)
Power consumption rate is subject to change according to conditions such as air
velocity, probe type and use of display.
Connection Wire Size 0.5 ~ 1.5 mm 2
Operating Temperature
Range
5 ~ 40 degrees C
Storage
Temperature Range
-10 ~ 50 degrees C
Dimensions Approx. 128(W)×78(D)×30(H)
Weight Approx. 320g
Standard Accessory
Operation Manual : 1
Main Unit Case: 1
Optional Accessory
Probe Cable (10m, 20m, 30m)
Display Unit (Supplied with a case with a display window and 2 installation screws.)
Dedicated AC Adapter (DC12V)
* Refer to “Specification of Probes” on page 16.
