3
SECTION 1 - INTrOduCTION
1.1 MICrO VOLuME ACCESSOry dESCrIPTION
The Genova Nano is a UV/visible spectrophotometer dedicated to life science analysis. This
spectrophotometer incorporates a micro volume sample measurement accessory that allows sample
volumes as low as 0.5μl to be analysed. The Genova Nano spectrophotometer is pre-programmed with
methods to determine DNA concentrations and purity ratios using wavelengths recorded at 260, 280
and 230nm, with an optional correction at 320nm and the Bradford, Lowry, Biuret, BCA and Direct UV
methods for protein analysis. When the micro volume accessory is removed, the Genova Nano reverts to
a standard Genova Plus spectrophotometer with measurement modes for photometrics, concentration,
multi-wavelength, spectrum scanning, quantitation and kinetics.
This life science spectrophotometer uses icon driven software and has an improved navigation system
for easy and intuitive usability.
1.2 MICrO VOLuME ACCESSOry SPECIFICATION
Genova Nano
Wavelength
Range 198 to 1000nm
Resolution 1nm
Accuracy ± 2nm
Repeatability ± 0.5nm
Spectral bandwidth 5nm
Photometrics
Absorbance range -0.300 to 2.500A
(10mm path length equivalent = -15.0 to 125.0A)
Accuracy ±2%@ 1A
Absorbance Precision Between 0 and 1A = <0.005, 1 to 2A = 2%, above 2A = 4%
dsDNA Detection Limit (0.5mm) 2.0 ng/μl
Maximum
Concentration (0.20mm) 6000 ng/μl
Stray light <0.5% at 340nm and 220nm
Other
Weight 1.5kg
Path lengths 0.2mm & 0.5mm
Measurement time <6.5s
Sample size 0.5 to 5.0μl
Operating Temperature 10 to 40°C
Operating Humidity 0 to 80% non-condensing
