INOR IPAQ C201 GB User Manual

Page 2

CALIBRATION

CONNECTIONS

Due to the low long-term drift of max ±0.1 % of span per year, a

recalibration of the transmitter is normally not needed. Should you for

any reason require a recalibration, the transmitter must be returned

to the factory.

INPUT CONNECTIONS

DIMENSIONS

MOUNTING

Head

mounting

kit

18.5/0.72

44.5/1.75

ORDERING INFORMATION

LIMITED WARRANTY

INOR Process AB, or any other affiliated company within the Inor Group (hereinafter

jointly referred to as ”Inor”), hereby warrants that the Product will be free from

defects in materials or workmanship for a period of five (5) years from the date of

delivery (”Limited Warranty”). This Limited Warranty is limited to repair or replace-

ment at Inor’s option and is effective only for the first end-user of the Product. Upon

receipt of a warranty claim, Inor shall respond within a reasonable time period as to

its decision concerning:

1 Whether Inor acknowledges its responsibility for any asserted defect in

materials or workmanship; and, if so,

2 the appropriate cause of action to be taken (i.e. whether a defective

product should be replaced or repaired by Inor).

This Limited Warranty applies only if the Product:

1 is installed according to the instructions furnished by Inor;

2 is connected to a proper power supply;

3 is not misused or abused; and

4 there is no evidence of tampering, mishandling, neglect, accidental damage,

modification or repair without the approval of Inor or damage done to

the Product by anyone other than Inor.

This Limited Warranty is provided by Inor and contains the only express war-

ranty provided.

INOR SPECIFICALLY DISCLAIMS ANY EXPRESS WARRANTY NOT

PROVIDED HEREIN AND ANY IMPLIED WARRANTY, GUARANTEE

OR REPRESENTATION AS TO SUITABILITY FOR ANY PARTICULAR

PURPOSE, PERFORMANCE, QUALITY AND ABSENCE OF ANY HID-

DEN DEFECTS, AND ANY REMEDY FOR BREACH OF CONTRACT,

WHICH BUT FOR THIS PROVISION, MIGHT ARISE BY IMPLICATION,

OPERATION OF LAW, CUSTOM OF TRADE OR COURSE OF DEALING,

INCLUDING IMPLIED WARRANTIES OF MER-CHANTABILITY AND

FITNESS FOR A PARTICULAR PURPOSE. EXCEPT AS PROVIDED HER-

EIN, INOR FURTHER DISCLAIMS ANY RESPONSIBILITY FOR LOSSES,

EXPENSES, INCONVENIENCES, SPECIAL, DIRECT, SECONDARY OR

CONSEQUENTIAL DAMAGES ARISING FROM OWNERSHIP OR USE

OF THE PRODUCT.
Products that are covered by the Limited Warranty will either be repaired or replaced

at the option of Inor. Customer pays freight to Inor, and Inor will pay the return

freight by post or other “normal” way of transport. If any other type of return freight

is requested, customer pays the whole return cost.

Pt100

Pt100

3-wire connection

IPAQ C201

70C2010010

Configuration

70CAL00001

ICON Configuration Kit (non-Ex)

70CFGUS001

Head mounting kit

70ADA00017

DIN-rail Adapter

70ADA00015

Supply voltage U (V DC)

LOAD

(

Ω) =(U-8.5)/0.022

OUTPUT LOAD DIAGRAM

53/2.08

10/0.39

DIN-rail

Adapter

mm/inches
