http://www.accusys.com.tw 21
User’s Manual
Disk Failure Message
LCD Display Message
Disk X failed.
Fan Failure Message
LCD Display Message
Fan failure. The xxxx rpm is the current rpm for the fan.
Overheating Error Message
LCD Display Message
System overheating. The XX is the current temperature
4.2. StorConn GUI introduction
ACS-77100 support remote RAID subsystem monitoring by web-based GUI. This section covers
the introduction of the monitoring software.
StorConn monitoring program, a
web-based GUI supporting In-band
interface via SATA channel and
Out-band interface via RS-232, by
which customers can monitor the RAID
status from web browsers at a remote
site. The StorConn is also capable of sending out notification mail to the customers.
Key Features
„
Graphical User Interface (GUI)
„ Multi-interface support
„ Remote monitoring
„ Web-based environment
„ Event notification
Temperature!!
XX°C > 50°C
Disk X fail
Fan Fail
XXXX rpm
