http://www.accusys.com.tw 18
User’s Manual
4. Management
4.1. LCD displayed Messages
The status of the ACS-77100 can be viewed through the LCD display. By using the scroll buttons
to scroll through the messages, the following information is available.
RAID level and capacity Disk drive model Disk capacity
Controller firmware version Controller serial number Fan and temperature status
4.1.1. Booting Messages
LCD Display Message
ACS-77100 is booting
ACS-77100 is initializing the installed disks
4.1.2. Set over 2TB Capacity Messages
LCD Display
Boot
RAID Box
RAID Box
Initialize Disks
Message
Press ENT button to set enable/disable over 2TB
Enable over 2T
Press ENT select
Enable over 2TB capacity
Enable over 2T
(YES)
Disable over 2TB capacity
Enable over 2T
(NO)
