HT instruments HT210 - Manual (Page 14)

HT210
EN - 13
4.3.7. Temperature measurement
CAUTION
Before taking temperature measurements in circuit remove power from the
circuit being tested and discharge all capacitors.
Fig. 8: Using the instrument for temperature measurement
1. Switch on °C or °F depend on the kind of measurement
2. Insert the standard adapter accessory into
V ΩTempHz%CAP
jack (+ polarity), and
COM jack (- polarity) (see Fig. 8)
3. Connect the standard bead type K probe or the optional type K probe (see paragraph
6.3.2) into the adapter with respect the correct positive and negative polarity then
temperature reading is displayed
4. If the message " O.L " is displayed the higher range is reached
5. For HOLD function please refer to paragraph 4.2
