Detcon DA-1 - Manual (Page 8)

7.0 Warranty
Detcon Inc., as manufacturer, warrants under intended normal use each new Model DA-1 data acquisition
module to be free from defects in material and workmanship for a period of one year from the date of ship-
ment to the original purchaser. Should the DA-1 fail to perform in accordance with published specifications
within the warranty period, return it to Detcon, Inc., for necessary repairs or replacement. All warranties and
service policies are FOB the Detcon Inc. facility located in The Woodlands, Texas.
Detcon Model DA-1 PG.8
mA
mA mA
mA
1 2 3
5 6 7
9 10 11
8
4
12
Fault
Power
Out
Power
In
COM
NO/NC A
B
A
B
1
2
3
4
RS-485
Digital Source
RS-485
CH1 CH2 CH3 CH4
mA
mA mA
mA
1 2 3
5 6 7
9 10 11
8
4
12
J1+
J2+ J3+
J1– J2–
J3–
No Jumpers
Interface Wiring for
Contact Closure Devices
Contact Closure Devices
Typical
