Detcon Model 1610A RACK

Panel Mount Control Enclosure

Operator's Instruction Manual

August 10, 2001 • Document #2471 • Version 1.0

1.0 INTRODUCTION

Detcon Model 1610A Rack consists of 3 major assemblies:

1. The NEMA 1 rack mount control enclosure.
2. The single channel digital control modules.
3. The remote mount gas sensor assemblies.
The NEMA 1 control enclosure is detailed in section 1.0 of the manual, the control modules in

section, 2.0 and applicable sensor assemblies in section 3.0.

1.1 DESCRIPTION

Detcon Model 1610A along with Model 10A digital control modules is designed to serve as a

host assembly for up to sixteen remote mount gas detection sensor assemblies. The control
enclosure is rated NEMA 1 suitable for installation in non-hazardous locations. The single chan-
nel modular design supports application flexibility wherein multiple function gas detection sys-
tems can be configured in any combination up to sixteen channels. All control modules are plug-
in front panel accessible for easy maintenance and repair.

Discreet output terminal strips located on the controller motherboard are provided for sensor

terminations, Form C dry contact alarm outputs (normally open, normally closed and common),
4-20 ma outputs for remote recording devices, alarm reset, and 24 VDC input.

Form C relay outputs may be discreet, zoned or common by gold plated jumper tabs located

on the controller mother board.

1.2 SPECIFICATIONS

ELECTRICAL CLASSIFICATION: NEMA 1
DIMENSIONS: 19"W, 5"H, 8.25"D

HIGH

LOW

FAULT

ALARM
RESET

HOUSTON, TEXAS

MODEL 10A

H2S MONITOR

ppm

LOCK

detcon inc.

HIGH

LOW

FAULT

ALARM
RESET

HOUSTON, TEXAS

MODEL 10A

H2S MONITOR

ppm

LOCK

detcon inc.

HIGH

LOW

FAULT

ALARM
RESET

HOUSTON, TEXAS

MODEL 10A

H2S MONITOR

ppm

LOCK

detcon inc.

HIGH

LOW

FAULT

ALARM
RESET

HOUSTON, TEXAS

MODEL 10A

H2S MONITOR

ppm

LOCK

detcon inc.

HIGH

LOW

FAULT

ALARM
RESET

HOUSTON, TEXAS

MODEL 10A

H2S MONITOR

ppm

LOCK

detcon inc.

HIGH

LOW

FAULT

ALARM
RESET

HOUSTON, TEXAS

MODEL 10A

H2S MONITOR

ppm

LOCK

detcon inc.

HIGH

LOW

FAULT

ALARM
RESET

HOUSTON, TEXAS

MODEL 10A

H2S MONITOR

ppm

LOCK

detcon inc.

HIGH

LOW

FAULT

ALARM
RESET

HOUSTON, TEXAS

MODEL 10A

H2S MONITOR

ppm

LOCK

detcon inc.

HIGH

LOW

FAULT

ALARM
RESET

HOUSTON, TEXAS

MODEL 10A

H2S MONITOR

ppm

LOCK

detcon inc.

HIGH

LOW

FAULT

ALARM
RESET

HOUSTON, TEXAS

MODEL 10A

H2S MONITOR

ppm

LOCK

detcon inc.

HIGH

LOW

FAULT

ALARM
RESET

HOUSTON, TEXAS

MODEL 10A

H2S MONITOR

ppm

LOCK

detcon inc.

HIGH

LOW

FAULT

ALARM
RESET

HOUSTON, TEXAS

MODEL 10A

H2S MONITOR

ppm

LOCK

detcon inc.

HIGH

LOW

FAULT

ALARM
RESET

HOUSTON, TEXAS

MODEL 10A

H2S MONITOR

ppm

LOCK

detcon inc.

HIGH

LOW

FAULT

ALARM
RESET

HOUSTON, TEXAS

MODEL 10A

H2S MONITOR

ppm

LOCK

detcon inc.

HIGH

LOW

FAULT

ALARM
RESET

HOUSTON, TEXAS

MODEL 10A

H2S MONITOR

ppm

LOCK

detcon inc.

HIGH

LOW

FAULT

ALARM
RESET

HOUSTON, TEXAS

MODEL 10A

H2S MONITOR

ppm

LOCK

detcon inc.
