INSTALLATION INSTRUCTION
Detcon Remote Cal /
Remote Sensor Separation Kit
Tubing for Cal
Gas
Remote
condulet with
sensor
Sensor
Transmitter
wiring to Control
Monitor
Applies to all Remote Separation Kits
DETCON, Inc.
3200 Research Forest Dr.,
The Woodlands, Texas 77387
Ph.281.367.4100 / Fax 281.298.2868
February 18, 2009• Document #2178• Revision 2.1
