A1V1-DV2
Sebtinel A1V1 Instruction Manual Rev.0.0 Page 4 of 5
3.0 Operation
The A1V1-DV2 Alarm Stations provide one strobe and a horn. The alarm station is set to respond to alarms
from the controlling unit. The controller has independent control over the strobe and the Horn, and they will
be activated when the appropriate alarm is activated.
All strobes have a flash rate of 1 Hz (one flash per second). This is preset by the manufacture and cannot be
modified.
The horn has up to 32 possible settings for use in different configurations. The default setting of the horn is
factory set. To change the setting of the horn, remove the rear end of the horn, and set dip switch according to
the Sound Signals Table.
Table 1 Sound Signals
TONE FREQ/DESCRIPTION SWITCH TONE
1 Alt Tones 800/970 Hz at 1/4 sec 11111
2 Sweeping 800/970 Hz at 7Hz 11110 Fast Sweep(LF)
3 Sweeping 800/1000 Hz at 1 Hz 11101 Med Sweep(LF)
4 Continuous at 2850 Hz 11100
5 Sweeping 2400-2850 Hz at 7 Hz 11011 Fast Sweep
6 Sweeping 2400-2850 Hz at 1 Hz 11010
7 Slow Whoop 11001 Slow Whoop
8 Sweep 1200-500 Hz at 1 Hz 11000 Din Tone
9 Alt. Tones 2400/2850 Hz at 2 Hz 10111
10 Int. Tone of 970 Hz at 1 Hz 10110 Back-Up Alarm(LF)
11 Alt. Tones 800/970 Hz at 7/8 Hz 10101
12 Int. Tone at 2850 Hz at 1Hz 10100 Back Up Alarm(HF)
13 970Hz at 1/4 sec on 1 sec off 10011
14 Continuous at 970 Hz 10010
15 554Hz for 100ms / 440 Hz for 400ms 10001 French Fire Sound
16 Int. 660 Hz 150 ms on 150 ms off 10000 Swedish Fire Alarm
17 Int. 660 Hz 1.8 sec on 1.8 sec off 01111 Swedish Fire Alarm
18 Int. 660 Hz 6.5 sec on 13 sec off 01110 Swedish Fire Alarm
19 Continuous 660 Hz 01101 Swedish Fire Alarm
20 Alt 554/440 Hz at 1 Hz 01100 Swedish Fire Alarm
21 Int. 660 Hz at 7/8 Hz 01011 Swedish Fire Alarm
22 Int. 2850 Hz 150 ms on 100 ms off 01010 Pelican Crossing
23 Sweep 800-970 Hz at 50 Hz 01001 Low Freq. Buzz
24 Sweep 2400-2850 Hz at 50 Hz 01000 High Freq. Buzz
25 3 970Hz pulses 0.5on/0.5off, 1.5 off 00111
26 3 2850Hz pulses 0.5on/0.5off, 1.5 off 00110
27 Int. 3100 Hz 0.32s on / 0.68s off 00101
28 Spare/Customer Tone 00100
29 Spare/Customer Tone 00011
30 Spare/Customer Tone 00010
31 Spare/Customer Tone 00001
32 Spare/Customer Tone 00000
