Model 1010-N4X
1010-N4X Instruction Manual Rev. 2.1 Page 8 of 10
Power Supply
Replacement of the power supply is accomplished by, removing the 10 screws that secure the 1010-N4X face
plate, disconnecting all wiring to/from the power supply, and removing the three screws holding the power
supply bracket to the Motherboard. Remove the four screws that hold the power supply bracket to the power
supply and reassembly with the new power supply. (Figure 6) Power Supply wiring is different between units
with and units without the battery backup option; attention should be paid to the correct wiring scheme for the
unit being worked on.
