SPEC SHEET
Web Site: www.adc.com
From North America, Call Toll Free: 1-800-366-3891 • Outside of North America: +1-952-938-8080
Fax: +1-952-917-3237 • For a listing of ADC’s global sales office locations, please refer to our web site.
ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101
Specifications published here are current as of the date of publication of this document. Because we are continuously
improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may
verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.
views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products orfeatures
contained herein may be covered by one or more U.S. or foreign patents. An Equal Opportunity Employer
101306AE 9/06 Original © 2006 ADC Telecommunications, Inc. All Rights Reserved
Description
Number
of Pairs
Unit
Makeup
Outer
Diameter
mm (inches)
Weight
Kg/Km
(lbs/1000')
Catalog Number
24 AWG STC, Dual Shield,
Riser
Jacket color: Gray
Packaging: Reel
Equivalent to 1107 Series
2 None 3.8 (.15) 19.3 (13) T0224HA-GYXX
4 None 4.8 (.19) 29.8 (20) T0424HA-GYXX
6 None 5.3 (.21) 40.2 (27) T0624HD-GYXX
8 None 7.1 (.28) 56.5 (38) T0824HD-GYXX
12 None 7.6 (.30) 78.9 (53) T1224HD-GYXX
16 None 8.4 (.33) 101.2 (68) T1624HD-GYXX
18 None 8.6 (.34) 110.1 (74) T1824HD-GYXX
25 None 9.9 (.39) 145.8 (98) T2524HD-GYXX
28 1 @ 25, 1 @ 3 10.0 (.39) 168.5 (113) T2824HD-GYXX
32 1 @ 25, 1 @ 7 10.2 (.40) 177.1 (118) T3224HD-GYXX
50 2 @ 12, 2 @ 13 13.9 (.55) 278.9 (187) T5024HD-GYXX
100 4 @ 25 18.3 (.72) 511.9 (344) T0024HD-GYXX
O r d e r i n g I n f o r m a t i o n
*To designate reel length,
replace XX as follows:
02 = 304 m (1000 ft)
04 = 609 m (2000 ft)
05 = 762 m (2500 ft)
06 = 914 m (3000 ft)
10 = 1524 m (5000 ft)
