Catskill Craftsmen 54228 - Manual (Page 3)

1 3/4” Phillips Flat Head Bolt (8)
1 1/4” Phillips Flat Head #8 Screw (16)
1” Truss Head Machine Screw (4)
5/8” Pan Head Screw (8)
3/4” Long 3/16” DIA. Steel Pin (4)
1” Long 3/16” DIA. Steel Pin (26)
1 1/2” Long 3/16” DIA. Steel Pin (8)
Hinge (3)
Caster Socket (4)
5/8 Wooden Disk (8)
Nickel Handle (6)
Towel Bar Post (2)
Wheel Casters (2) Locking Wheel Casters (2)
Magnet Plate (4) Magnet (4)
3/16” Flat Washer (8)
10-24 Hex Nut (8)
5/8” Phillips Flat Head #8 Screw (26)
5/8” Phillips Flat Head #5 Screw (4)
(Used on “L” Brackets
and cabinet glides)
(Used on Cabinet Glides)
1/2” Phillips Flat Head #4 Screw (4)
(Used on Magnet Plate)
(Used on Magnet)
2” Long 3/16” DIA. Steel Pin (8)
Bastion Set Screw (2)
Bastion Post (2)
Bastion Barrel Nut (2)
“L” Bracket (4)
Drawer Glide (1 Set )
Drawer
Cabinet
P/N Drop Leaf Support (2)
Hardware for 54228
Polished Nickel Towel Bar (1)
1 1/2” Phillips Flat Head #8 Screw (2)
5/8” Phillips Flat Hed #7 Screw (12)
Retainer Rods for Spice Rack (2)
1” Phillips Flat Head #8 Screw (4)
Magnet Pack
(Brace Pin)
(Shelf Pin)
(Door Pin)
(Divider Pin)
(Attaches drop leaf hardware)
(Attaches
drawer handles)
(Attaches towel bar & spice rack)
(8 are bronze for spice rack)
(attach drawer back)
7/8” Truss Head Machine Screw (8)
(Attaches door handles)
