Catskill Craftsmen 64026 - Manual (Page 3)

Hardware 64026
Caster Socket (4)
P/N: SET SCREW
Bastion Set Screw (10)
P/N: B-NUT
Bastion Barrel Nut (10)
P/N: B-POST
Bastion Post (10)
5/8” Wooden Disk (12)
(Packed with Hardware)
P/N: SPACER
Plastic Spacer (4)
(Goes between cabinet
drawer glide & side panel)
Butterfly
Brackets (4)
IMPORTANT NOTE ON SCREWS: Separate screws
into piles with a note on use as some are very similar.
DO NOT use the larger diameter 5/8” #8 screws to
attach the drawer glides. Screws for the glides have
flat heads & are much smaller in diameter. Double Check!!
Drawer Glide (1 Set )
Drawer
Cabinet
P/N: WHEEL 2L (LOCKING)
Locking Wheel Casters (2)
P/N: WHEEL 2 (NON-LOCKING)
Wheel Casters (2)
P/N: HANDLE 64024
Nickel Handle (3)
1 1/4” Phillips Flat Head #8 Screw (16)
5/8” Pan Head Screw (4)
3/4” Long 3/16” DIA. Steel Pin (4)
1” Long 3/16” DIA. Steel Pin (40)
1 1/2” Long 3/16” DIA. Steel Pin (4)
Magnet Plate (2)
Magnet (2)
1/2” Phillips Flat Head #4 Screw (2)
(Used on Magnet Plate)
(Used on Magnet)
Magnet Pack
(Door pins)
(Shelf pins)
(Brace pins)
1” Truss Head Machine Screw (6)
(used on door/
drawer handles)
1” Phillips Flat Head #6 Screw (4)
(used to attach cabinet
drawer glides)
5/8” Phillips Flat Head #8 Screw (8)
(used to attach
butterfly bracket)
5/8” Phillips Flat Head #5 Screw (4)
(used drawer glides)
3/16” Flat Washer (2)
