CABINET HARDWARE
1 3/4” Phillips Flat Head Bolt (12)
1 1/4” Phillips Flat Head #8 Screw (4)
1” Truss Head Machine Screw (6)
5/8” #6 Pan Head Screw (2)
5/8” Phillips Flat Head #8 Screw (10)
3/4” Long 3/16” DIA. Steel Pin (14)
1” Long 3/16” DIA. Steel Pin (8)
1 1/2” Long 3/16” DIA. Steel Pin (4)
Hinge (4)
Caster Socket (4)
Wheel Casters (2) Locking Wheel Casters (2)
Magnet Plate (1)
Magnet (1)
3/16” Flat Washer (2)
10-24 Hex Nut (12)
5/8” Phillips Flat Head #6 Screw (16)
5/8” Phillips Flat Head #5 Screw (4)
1/2” Phillips Flat
Head #4 Screw (1)
Bastion Set Screw (2)
Bastion Post (2)
Bastion Barrel Nut (2)
Drawer Glide (2 Sets )
Drawer
Cabinet
P/N Drop Leaf Support (2)
1 3/4” Phillips Flat Head #8 Screw (2)
Handle (3)
( Used on Cabinet Side Glides )
( Used on Drawer Side Glides )
“Z” Bracket (2) 5/8” Wooden
Disk (12)
The glides look almost alike
however, the right glide (as you
face the cart) has a rolled lip at
the top of the glide that keeps
the drawer glide wheel in place.
(Cabinet Bolt)
(Attaches Cabinet
to Top - Front)
(Door Pin)
(Shelf Pin)
(Brace & Brace Panel Pin)
(Handle Screw)
(Drop Leaf Supports)
May be bronze in color
Note: Handles may be
packed with screws -
discard use screws in
hardware pack.
