STEP 1
Tools needed: medium Phillips screwdriver
Hardware needed: (4) wood screws 1 3/4” #8
Parts needed: (2) Table Ends, (2) Feet
Preparation: dip screw tips in vegetable oil to
ease installation of screws into hardwood.
Invert Table ends (identical) and attach feet (identical) with
1 3/4” #8 screws as shown in illustration 1
Illustration 1
STEP 2
Illustration 2
Tools needed: medium Phillips screwdriver
Hardware needed: (4) 2” machine screws and (4) nuts
Parts needed: Table Ends with feet attached
and the bottom support brace
Join the leg assemblies at bottom
support brace using (2) machine
screws/nuts per side. Place
nut on finger tip, insert into
the nut access hole in the
brace, align with machine
screw and loosely tighten so that
frame stands alone.
