STEP 10

A. Insert one 3/4 pin into the end of each stemware holder. Orient holder as shown in the

illustration and put pins into holes in the back panel.

B. Attach the stemware holders to the bottom edge of the top front brace using 1 #8 screws.

C. Insert and tap caster sockets with hammer until the teeth grab the wood.

DONT POUND SOCKET FLAT OR CASTER SHAFT WILL NOT ENTER.

D. Insert casters and seat by pushing straight downward with heel or your hand, or tap into

place with a hammer. Dont be afraid to give them a good downward whack on the solid

metal part of the caster! Locking casters are usually most functional when placed on the

front of the cart.

5 used

in this step

1 Phillips Flat Head #8 Screw

3/4 Long 3/16 DIA. Steel Pin

5 used in this step
