Hydraulic High Pressure Calibration Pump
Additel 936
OVERVIEW
The 936 Hydraulic High Pressure Test Pump is a hand operated pressure pump designed to generate pressure from
85% vacuum to 15,000 psi (1,000 bar). With the patented screw press technology, high pressures can be easily
generated, as well as increased and decreased smoothly. A specially designed shut-off valve makes the pressure
as stable as possible during calibration. With no check valve (non-returning valve), the 936 avoids the troublesome
leakage issues that is usually experienced with hand pumps and allows for minimal maintenance. Three hand-tight quick
connectors installed on the pump allow easy connecting and disconnecting to the test pump without the need for PTFE
tape or wrenches. The 936 is an ideal comparison test pump for calibrating pressure measuring instruments such as test
gauges, indicators or transducers in the laboratory.
High Pressure
Generates pressure up to 15,000 psi (1000 bar)
Durable and Minimal Maintenance
Patented screw press technology, without non-
returning valve inside that is usually used on
troublesome hand pumps.
Easy-to-use
High pressures can be generated easily, as well
as increased and decreased smoothly.
Extremely Low Leakage
Patented screw press technology replaces
troublesome check valves (non-returning valve)
in most hand pumps which practically eliminates
leakage.
Hand-tight Quick Connectors
Allows easy connecting and disconnecting to
the test pump without the need for PTFE tape or
wrenches.
Media: Oil
Pressure Range
85% vacuum to 15,000 psi (1,000 bar) positive.
Material
Ram/adapters: SS
Body: SS/aluminum
Seals: Buna-N
Connection
Hand-tight connectors for both test gauge and
reference gauge(s).
Test Gauge Connection: 1/4NPT female, 1/4BSP
female, or M20X1.5 female
Reference Gauge Connection: 1/4NPT female, 1/4BSP
female, or M20X1.5 female
Dimensions
Height: 9.1'' (230 mm)
Base: 20.5'' (520 mm) x 14.2'' (360 mm)
Weight: 35.2 lb (16 kg).
Warranty: 1 year
FEATURES SPECIFICATIONS
ORDERING INFORMATION
Accessories included
Diethylhexyl Sebacate oil,1 bottle (250 ml)
O-ring: 20 pcs Manual: 1 pc
Pressure port type:
N-
1/4NPT female
N2-1/2NPT female
B-1/4BSP female
M-M20X1.5 female
Model
ADT936 N
Model Number
Optional Accessories
Model number Description
9201 Oil, Diethylhexyl Sebacate, 1 liter (1 quart)
ADT102
Adapters and fittings, 1/4NPT male to various male and female connection
(25 pcs). More information shown on page 53.
ADT103
Adapters and fittings, 1/4NPT (1/4BSP, or M20X1.5) male to various
female hand-tight quick connectors (10 pcs). More information shown on
page 54.
9908 Carrying case for 936, 937, 938 or 949.
ADT936-MK Maintenance kit for Additel 936 pump
Generate 85% vacuum to 15,000 psi (1,000 bar) pressure
Minimal maintenance
Increase and decrease pressure smoothly
Three pressure ports
Hand-tight quick connectors
