Handheld Pneumatic Pressure Test Pump
Additel 914
OVERVIEW
The 914 Pneumatic Pressure Test Pump is a hand operated pressure pump designed to generate pressure from 95%
vacuum to 375 psi (25 bar). A high-quality screw press is designed for fine pressure adjustment, with an adjustment
resolution up to10 Pa (0.1 mbar). A specially designed shut-off valve makes the pressure as stable as possible during
calibration. A built-in gas-liquid isolator protects the pump from moisture and dirt to reduce the need for maintenance.
Two hand-tight quick connectors installed on the pump allow easy connecting and disconnecting to the test pump
without the need for PTFE tape or wrenches. The 914 is an ideal comparison test pump for pressure instruments
calibration.
FEATURES
ORDERING INFORMATION
Portable:
Only 3.3 lb (1.5 kg)
Adjustment Resolution
10 Pa (0.1 mbar)
High-quality screw press for fine pressure adjustment
Great Stability
A specially designed shut-off valve makes the
pressure as stable as possible during calibration
Durable and Minimal Maintenance
Built-in gas-liquid isolator protects the pump from
moisture and dirt
Easy-to-use
Hand-tight Quick Connectors
Allows easy connecting and disconnecting to the test
pump without the need for PTFE tape or wrenches
SPECIFICATIONS
Media: Air.
Generated Pressure Range: 95% vacuum to 375 psi (25
bar) positive pressure
Adjustment Resolution: 10 Pa (0.1 mbar).
Material: Ram/adapters: SS
Body: SS/aluminum
Seals: Buna-N
Connection
Hand-tight connectors for both test gauge and
reference gauge.
Test Gauge Connection: 1/4NPT female, 1/4BSP
female, or M20X1.5 female
Reference Gauge Connection: 1/4NPT female,
1/4BSP female, or M20X1.5 female
Dimensions
Height: 5.12'' (130 mm)
Base: 9.45'' (240 mm) x 4.72'' (120 mm)
Weight: 3.3 lb (1.5 kg).
Warranty: 1 year
Optional Accessories
Model number Description
ADT102
Adapters and fittings, 1/4NPT male to various male and female connection
(25 pcs). More information shown on page 53.
ADT103
Adapters and fittings, 1/4NPT (1/4BSP, or M20X1.5) male to various
female hand-tight quick connectors (10 pcs). More information shown on
page 54.
ADT100-HTK
Hose test kit, 5 feet flexible hose, 15,000 psi, 1/4NPT male to 1/4NPT
(1/8NPT, 1/2NPT, 1/4BSP, or M20X1.5) female hand-tight quick
connector. More information shown on page 55.
9901-914 Carrying Case for one 914 pump and two 681 gauges or 672 calibrators
ADT914-MK Maintenance kit for Additel 914 pump
Accessories included
O-ring: 20 pcs
Manual: 1 pc
Pressure port type:
N-1/4NPT female
N2-1/2NPT female
B-1/4BSP female
M-M20X1.5 female Model
ADT914 N
Model Number
Generate 95% vacuum to 375 psi (25 bar) pressure
Portable, only 3.3 lb
Great stability and high resolution
Minimal maintenance
Hand-tight quick connectors
