Gauge Profile
 Scale
Reading multiplying factor (range: 0.900 to 1.100). Standard value should be 1.000.
If display is 1.500, when we key-in the reading multiplying factor to 1.1. The display
will change to read 1.650 (1.500 x 1.100)
Reading offset value. If we offset the reading of 0.123, then all the reading will be minus
0.123 even you off the power and on again. It is different from the zeroing.
 Resolution
Selection of Resolution. It is able to select the decimal point at which position. In the
down list, you can select 5 or 6.
4. Logging
Softwae will display the real-time pressure value and the real-time chart. However it has
not stored these data yet, users need to click the “start all” under the “log” menu or to click
the button on each frame of UUTs to start storing.
When users want to stop storing data, they can click the “Stop All” under “Log” menu or
buttons on each frame of UUTs.
5. Clear
Users can delete the stored data by clicking button on toolbar or on each
frame of UUTs. When the deleting operation is finished, it will re-start another logging task
automatically.
6. Unit
Users can define engineering unit by clicking button
on toolbar. There is a field
for users to define engineering unit by themselves. The Reference Unit can be kPa or PSI.
