WEN 2275 5 Gallon Pancake Air Compressor User Manual
Page 3

#2275OPERATOR’SMANUAL
3
®
TABLE OF CONTENTS
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
ImportantSafetyInstructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
GeneralSafetyInstructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–6
AirCompressorSafetyInstructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–7
ElectricalInstructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7–9
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
AssemblyInstructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12–13
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13–15
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Service..............................................16
ExplodedView . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
PartsList.............................................18
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
5-Gallon Pancake Air Compressor
Item#:
2275
Motor:
120V,60Hz,13Amps
PressureRange:
85–125psi
AirFlow:
4.2CFM@40psi
3.2CFM@90psi
AirOutletSize:
1/4"NPT
TankCapacity:
5-Gallons
Weight:
48lbs.
SPECIFICATIONS
