WEN 6502 4 x 6 Belt / Disc Sander User Manual
Page 2
TABLE OF CONTENTS
Technical Data
2
3
4
6
7
8
12
14
15
17
19
General Safety Rules
Specific Safety Rules For Belt/Disc Sander
Electrical Information
Know Your Belt/Disc Sander
Assembly and Adjustments
Operation
Maintenance
Exploded View and Parts List
Warranty
TECHNICAL DATA
Model Number:
Motor:
Speed:
Disc Diameter:
Belt Size:
Belt Speed:
Belt Bed Tilt:
Belt Grit:
Dust Port Size:
Net Weight:
6502
120 V, 60 Hz, 4.3 A, 1/2 HP
3600 RPM (no load)
6˝
4˝ x 36˝
1900 SFM
0 to 90°
A80
2-1/4˝
41 lb
2
Troubleshooting
