Specifications


Model Number

70716

Input Power

120V, 60Hz, 15A

No Load Speed

5500 RPM

Blade Size

10" x 5/8" bore

Number of teeth

60

MiterTable Angles

0° to 52° Left & Right

Bevel Cuts

0° to 45° Left only

Weight

29.7 lbs


Cutting Capacity

Straight cut

at 0° miter, 0° bevel: 3-1/4x11-/5/8"

Miter cut

at 45° miter, 0° bevel: 3-1/4x8-1/16"

Bevel cut

at 0° miter, 45° left bevel: 1-5/8x11-5/8"

Compound miter cut

at 45° left miter, 45° left bevel: 1-5/8x8-1/16"



The WEN 10" Sliding Compound Miter Sawis supplied with the following accessories as standard:
• Saw blade (installed)

• Hold down clamp

• 6 mm hex key

• 2 material support arms

• Dust collection bag

• Instruction manual
