Wellsaw 1348 - Manual (Page 27)

25
Hydraulic System
*NOTE:
On saw model 1118 before S/N 1171, model 1338
before S/N 1733 and Model 1348 before 4809, there
is no cylinder service kit.
Replace the cylinder with part # 155180 & 150277.
1 1000004-115 Cap Screw, HH 1/2-13 x 3-1/2
(before S/N 1300)
2 150218 Clevis
3 100019-026 Heavy Hex Jam Nut, 1/2-20
4 150265 Hydraulic Cylinder (No Longer Available- use 155180 & 150277)
(Used on Model 1118 before S/N 2584, Model 1338 before 1733 and Model 1348 before 4809)
155180 Hydraulic Cylinder
(Used on Model 1118 after S/N 2584, Model 1338 after 1733 and Model 1348 after 4809)
5 100313-001 90 deg. Swivel Fitting, 1/4
6 100331-034 Hose Assy, top 1/4 x 50
7 100004-052 Cap Screw, HH 3/8-16 x 3-1/2
8 150219 Cylinder Bracket, Lower (before S/N 1300)
9 100238-005 Feed Control Valve
10 150278 Pointer
11 100034-009 Set Screw, 10-32 x 1/4
12 100329-001 Swivel Fitting, Straight
13 150269 Hydraulic Cylinder Field Service Kit for 150265
(includes items 14-17)
14 150266 Glide Ring
15 150267 Piston Cup
16 150268 Cup Retainer
17 100069-012 External Snap Ring
18 098049-001 Dash Pot Oil, 8 oz (2 req'd)
19 155181 Cylinder
20 155164 External Hitch Pin
21 155163 Spring
22 100028-006 Shake Proof Washer
23 155161 Piston Cup
24 155160 Aluminum Washer
25 155159 Spring
26 155221 Piston Rod Ass'y for 155180 (includes Rod and items 20-24)
27 155156 O-ring, Buna N 2-208
28 155157 Cylinder Cap
29 155256 Hydraulic Cylinder Field Service Kit for 155180
(includes items 20-23 & 27)
30 150277 Lower Cylinder Mount (after S/N 1300)
31 100008-006 FH Socket Head Capscrew, 3/8-16 x 1
32 150279 Clevis Pin (after S/N 1300)
33 100069-019 Snap Rin (2 req'd)
34 107065 Nylon Washer
35 100331-035 Hose assy bottom 1/4" x 60"
