19
Blade Guide Assembly Blade Guide Assembly
1 101522 Blade Guide Ass’y, D.E. Complete
(before S/N 1300)
(includes 5-12 & 17-23, 26 & 27)
101522-004 Blade Guide Ass’y, D.E. Complete
(S/N 1300 thru 1999)
(includes 5-27, minus 13)
2 105406 Blade Guide Ass’y, I.E. Complete
(before S/N 1300)
(includes 5-11,13, 17-23, 26 & 27)
105406-004 Blade Guide Ass’y, I.E. Complete
(S/N 1300 thru 1999)
(includes 5-27, minus 12)
3 150061 Roller Support Ass’y, D.E.
(includes 14-27 & 12)
(S/N 1300 thru 1999)
101521 Roller Support Ass’y, D.E.
(includes 12,17,20-23,26 & 27)
(before S/N 1300)
4 106659 Roller Support Ass’y, I.E.
(Includes 13 thru 27)
(S/N 1300 thru 1999)
105408 Roller Support Ass’y, I.E.
(includes 13,17,20-23,26 & 27)
(before S/N 1300)
5 105335-001 Hand Wheel Ass’y
6 150118 Roller Guide Bracket
7 100034-006 Set Screw, 5/16-18 x 7/8 (2 req’d)
8 100034-005 Set Screw, 5/16-18 x 3/4 (2 req’d)
9 M-092 Roller Adjuster (before S/N 1300)
150287 Roller Adjuster (after S/N 1300)
10 100004-018 Cap Screw, HH 5/16-18 x 1
11 100029-002 Flat Washer, 1/4
12 106389 Roller Support, Drive End
(S/N 1300 thru 1999)
101180 Roller Support, Drive End
(before S/N 1300)
13 106315 Roller Support, Idle End
(S/N 1300 thru 1999)
105396 Roller Support, Idle End
(before S/N 1300)
14 100008-018 Cap Screw, SH 5/16-18 x 3/4
15 106317 Fixed Carbide Guide (after S/N 1300)
16 106319 Spring Back Carbide Guide
(S/N 1300 thru 1999)
17 101300 Hex Nut, 5/16-18
18 100004-016 Cap Screw, HH 5/16-18 x 7/8
19 100029-002 Flat Washer, 1/4
20 101186 Roller Guide Washer (3 req’d)
21 100416-003 Ball Bearing (2 req’d)
22 101178 Roller Axle
23 101177 Eccentric Roller Axle
24 100127-003 Set Screw, Nylon Pt. 1/4-20 x 5/16
25 106285 Guide Pre Load Ass’y
26 101179 Roller Axle Back Up
27 100406-002 Ball Bearing
28 100220-038 Coolant Hose, I.E., 37”
100220-039 Coolant Hose, D.E., 13”
29 100219-001 Hose Clamp
30 102617 Adapter
31 100226 Needle Valve
32 150288 Coolant Nozzle
33 100246-001 Pipe Strap (2 req’d)
34 100000-018 Machine Screw, 10-32 x 3/8 (4 req’d)
1 150272 Blade Brush Ass’y (includes 2 - 8)
2 100019-005 Hex Jam Nut, 1/2-13
3 100030-007 Flat Washer, 1/2 (2 req’d)
4 100133-004 Brush
5 150257 Brush Housing
6 100404-001 Ball Bearing (2 req’d)
7 150126 Brush Arbor
8 100167-003 Small Pulley w/set screw
9 100165-015 Shoulder Bolt, SH 3/8 x 1-1/2
10 150369 Blade Brush Arm
(Model 1118 after S/N 1885)
150127 Blade Brush Arm
(Model 1118 before S/N 1885)
11 100004-015 Cap Screw, HH 5/16-18 x 3/4
12 100042-003 Thumb Screw, 1/4-20 x 2
13 100024-002 Wing Nut, 1/4-20
14 100165-007 Shoulder Bolt, 3/8 x 3/8
15 150360 Spring
16 150364 Belt Tension Arm
17 100069-013 Snap Ring
18 100097-001 Washer
19 150361 Pulley, Belt Idler
20 100166-450 V’ Belt
21 100416-001 Ball Bearing
22 B-043 Axle
23 100004-018 Cap Screw, HH 5/16-18 x 1
24 100025-002 Lockwasher, 5/16
25 150160 Door Latch Stud 1118 before 2584; 1338
before 1724; 1348 before 4808
150160-002 Door Latch Stud 1118-1318 after 2584
1338 after 1724, 1348 after 4808
Model 1118 Serial Number 1999 and Earlier
Model 1338 Serial Number 1646 and Earlier
Blade Brush Assembly Blade Brush Assembly
Note: Adjust thumb screw (12) so that the brush makes
light contact with the blade. This avoids dulling the
blade and prevents premature brush wear.
