TrueNet
®
Intelligent
Patching
TrueNet ® Intelligent Patching
Active Hardware
2 w w w . a d c . c o m + 1 - 9 5 2 - 9 3 8 - 8 0 8 0 1 - 8 0 0 - 3 6 6 - 3 8 9 1
Description Catalog Number*
Intelligent Patching Scanner 6527 1 730-00
Intelligent Patching Master 4 Ports 6527 1 733-00
Intelligent Patching Master Expander 6527 1 732-00
Intelligent Patching Expander 6527 1 734-00
Intelligent Patching Indicator Controller 6527 1 735-00
Intelligent Patching Control Pad 6527 1 736-00
Intelligent Patching Mini Scanner 6527 1 739-00
Intelligent Patching Network Scanner 6527 1 741-00
Intelligent Patching Rack Indicator 6527 1 737-00
Intelligent Patching Scanner Attachment Cord Copper UTP 6527 1 750- XX
Intelligent Patching Scanner Attachment Cord Fiber 6527 1 751- XX
*Replace XX with: 1.5 m = 51, 2.5 m = 52, 6 m = 06, 12 m = 12
O r d e r i n g I n f o r m a t i o n
Specifications
(Excludes 6527 1 736-00)
MECHANICAL
Panel Rack Mounting:
1U 19" (IEC 60297)
Panel Dimensions: 44 mm x 483 mm x 160 mm deep
Weight: 2.0Kg (4.4lbs)
INtERfACEs
UP/DOWN LINKs:
Standard RS-485, Full – duplex connector shielded RJ-45 socket
Data rate up to 115.2 Kbps
100Base tX: RJ-45 socket, Ethernet IEEE 802.3, 100 100Base Tx/10Base T,
100/10 Mbps industry standard for connection to local area network.
serial: RS-232 Connector 9-pin D-type male
Data rate up to 115.2 Kbps
Protocol UART, Start bit 1, Stop bit 1, Nonparity
Control Pad: Connector RJ-45 socket, 8 pins
Patch Panel Connections: Connectors 6 or 12 headers, 26-pin, 100mm spacing
LED INDICAtORs (WHERE UsED)
PWR:
On when scanner is powered
CPU: Blinking to indicate master heartbeat
DOWN LINKYELLOW: On during transmission of each of the DOWN LINK ports
DOWN LINKGREEN: On during reception of each of the DOWN LINK ports
100Base tx – Rx: On during reception from local area network
100Base tx – tx: On during transmission to local area network
100Base tx LINK: On when link is active
ENvIRONMENtAL & sAfEtY
Operating temperature range: 0° C - +50° C
Operating humidity range:
≤ 90% RH non-condensing
safety: UL 60950, EN 60950
EMC: EN 55022, FCC part 15 Class A, EN 55024
Power: 100 – 240 VAC, 47 – 63 Hz, 30 W maximum
