REPLACEMENT PARTS
We make every effort to ensure that all units ship complete with all parts and arrive undamaged. However, should
your unit contain missing or damaged parts, replacements may be obtained directly from us. To obtain proper
replacement parts, follow the instructions below:
l
l
l
l
l
l
l
l
TO OBTAIN PROPER REPLACEMENT PARTS, PLEASE PROVIDE THE FOLLOWING INFORMATION:
Model Number (1430) Purchase Date
Description of part(s) needed and part Your company name
number(s) as shown in Parts List (above) Contact person's name
Color (i.e. Medium Grey, etc.) Who the product was purchased from
Was item missing, or was it damaged?
Tennsco Corp., P.O. Box 1888, Dickson, TN 37056-1888 Customer Service: (866) 446-8686 Fax: (800) 722-0134
If requesting parts by telephone, ask for customer service and have as much of the above information ready as possible.
Cam Retainer
(Ref. No. 14)
Right Side
(Ref. No. 3)
Sill
(Ref. No. 6)
Back Panel
(Ref. No. 1)
Locking Cam
(Ref. No. 13)
Locking Handle
with Keys
(Ref. No. 12)
REF. NO. PART NO. DESCRIPTION
1 Back panel 1 086BA
2 Left side 1 086LS
3 Right side 1 086RS
4 Shelf 2 301
5 Header 1 944HE
6 Sill 1 944SI
7 Bottom 1 944BO
8 Top 1 978CT
9 Left door 1 086LD
10 Right door 1 086RD
11 Locking bar set 1 086LB
12 Locking handle w/keys & hardware 1 944LH
13 Locking cam* 1 944LC
14 Cam retainer* 1 944CR
15 Locking bar guide insert (nylon)* 2 944GI
16 Hinge pin 6 944HP
17 Tennsco nut driver 1 TOOL-2
18 #8-32 x 3 / 8 "bolts* 23 AVAILABLE LOCALLY
19 #8-32 nuts* 29 AVAILABLE LOCALLY
*Included in Ref. No. 12, locking handle with keys and hardware (Part No. 944LH).
QTY.
Shelf
(Ref. No. 4)
Bottom
(Ref. No. 7)
Left Side
(Ref. No. 2)
Top
(Ref. No. 8)
Left Door
(Ref. No. 9)
Right Door
(Ref.
No. 10)
Locking Bar Guide
Nylon Insert
(Ref. No. 15)
Locking Bar Set
(Ref. No. 11)
Hinge Pin
(Ref. No.
16)
Header
(Ref. No. 5)
Tennsco Nut Driver
(Ref. No. 17)
