IMPORTANT NOTES
 Using or attaching other accessories or devices can cause a hazard, may damage the unit, and WILL
VOID the WARRANTY.
INSTALLING THE Smart Light 2000 ™
IMPORTANT-DISCONNECT THE BATTERY
STEP 1: Remove the old lighting fixture from the RV and clean area of all old sealer, dirt, etc.
NOTE: If you are using the optional Fuse Box to activate your Scare Light now is the time
to add that accessory using the installation instruction included with the Fuse Box.
STEP 2: Attach the WHITE wire marked positive (+) on the SL-2000™ fixture to the positive wire (+)
coming from the RV.
STEP 3: Attach the WHITE wire marked negative (-) on the SL-2000™ fixture to the negative wire (-)
coming from the RV.
NOTE: Perform functionality test at this step
The Smart Light 2000 ™
is reverse polarity protected. If it is wired backwards, the unit will not be
damaged. However, if wired incorrectly, the motion sensing functionality will not work, even though the
light can be turned on and off at the switch as with any other porch light. Thus, it is imperative that you
perform this self test in order to assure proper functionality. To do this test you will have to reconnect the
battery.
First, adjust your interior light switch to the ‘ON’ position. Then, turn the light switch ‘OFF’, then ‘ON’
again. If at this point you find that the incandescent light bulb turns on, but the
BLUE LED does not blink
on and off, then switch the positive and negative wires connecting the Smart Light to your vehicle. Next,
perform the self test once again as described above. If your light again fails to operate in the auto mode as
indicated, please stop the installation process and contact us at 1-800-883-5444. If the functionality test is
successful, again DISCONNECT THE BATTERY and proceed with the installation.
STEP 4: Using the FOUR (4) screws provided, attach the Smart Light 2000 ™ fixture to the exterior of the
RV. In most cases, the previous holes used to mount the old fixture can be reused to mount the
Smart Light 2000
™ . However, if you must drill new screw holes into your substrate, make sure to
properly fill in the old holes before mounting your light.
STEP 5: Remove the Clear plastic plug to gain access for the adjustment of the Variable Resistor
(Potentiometer) for sensitivity. The adjustment is clockwise to increase sensitivity, and
counterclockwise to decrease sensitivity. When adjusting this resistor, take care not to touch the
mother board, which could damage the unit and WILL VOID the WARRANTY. Please note
that the Smart Light 2000
™ fixture comes from the factory set at the most sensitive setting and
may need adjustment to a lower sensitive setting to match the camping environment.
IMPORTANT – DISCONNECT THE BATTERY BEFORE ADJUSTING
The Potentiometer is located on the circuit board mounted in the electronics compartment of the Smart
Light 2000
™
fixture located above the light sensor and below the multicolored LED. To adjust the
NOTE:
Some models may have differing hole depths and/or widths. Thus, the screws provided may not be
sufficient. If you find this to be the case on your model, simply substitute the enclosed screws for those that
will fasten the unit properly.
