Chapter 3

60

M2.5*6

Remove the IO bezel then
you will see.

2

M2.5*6

Remove the heatsink cover
then you will see.

1

M2.5*6

Remove the HDD cover then
you will see.

1

M2.5*3

Detach the HDD module
then you will see.

1

M2.5*3

Remove the battery then you
will see.

1

Screw Type

Location

Quantity
