Chapter 1 35
12 function keys ! four cursor keys
! two Windows keys
! Hotkey controls
! embedded numberic keypad
! international language support (for
TM4600/TM4100)
Four easy-launch buttons ! Internet browser
! email with LED
! Empowering key
! one user-programmable button
Two front access LED buttons ! WLAN LED button
! Bluetooth LED button
Battery
Item Specification
Vendor & model name Panasonic/Sanyo
Battery Type Li-ion
Pack capacity 65Wh
Cell voltage 3.7V/cell/2000mAh High discharge rate
Number of battery cell 8-cell(65W)
4-cell(32W)
Package configuration
Pin 1
Pin 2 BATT+: Battery+, Battery Positive Terminal
Pin 3 ID : Identify Pin (Note 1)
Pin 4 B/I : Battery-In Pin
Pin 5 TS : Connect to Thermister
Pin 6 SMD : SMBus data interface I/O pin
Pin 7 SMC : SMBus clock interface I/O pin
Pin 8
Pin 9 GND : Battery Negative Terminal
Keyboard
Item Specification
