Operating the Spreader

BAFFLE INSTRUCTIONS

• The V-Maxx 8550 uses a dual baffle design over the auger area.

This baffle (D6809) is used for dry bulk materials. The baffle is
designed to reduce the risk of leakage with clean/dry free-flowing
materials. If the material you are using is damp/wet, you may need
to remove baffle (D6809). This will allow for more unrestricted flow
of materials and possible bridging.

• WARNING: Always disconnect power source before attempting to

remove material baffle.

• The main baffle assembly (D 6808) MUST never be removed from

its original factory installed position unless the unit is being
serviced or the Optimum Flow Kit is being installed.

BAFFLE EXTENSION INSTRUCTIONS

• The Baffle Extension is installed at the time of assembly. The main

purpose of this baffle is to keep dry, free-flowing material from
leaking out.

• If you plan on using damp/wet materials, you should remove this

baffle by removing the self-drilling screws.

• If you are using a sand/salt mixture, remove baffle extension.

D6809

Key

Part No.

Description Qty.

D 6847

Salt Baffle Extension 1

D 6807

Discharge Baffle 1

D 6874

#14 x 1-1/2" TEK w/Neo Washer 2

Model # SP-8550
