Operating the Spreader
BAFFLE INSTRUCTIONS
• The V-Maxx 8500 uses a dual baffle design over the auger area.
This baffle (D6809) is used for dry bulk materials. The baffle is
designed to reduce the risk of leakage with clean/dry free-flowing
materials. If the material you are using is damp/wet, you may need
to remove baffle (D6809). This will allow for more unrestricted flow
of materials and possible bridging.
• WARNING: Always disconnect power source before attempting to
remove material baffle.
• The main baffle assembly (D 6808) MUST never be removed from
its original factory installed position unless the unit is being
serviced or the Optimum Flow Kit is being installed.
BAFFLE EXTENSION INSTRUCTIONS
• The Baffle Extension is installed at the time of assembly. The main
purpose of this baffle is to keep dry, free-flowing material from
leaking out.
• If you plan on using damp/wet materials, you should remove this
baffle by removing the self-drilling screws.
• If you are using a sand/salt mixture, remove baffle extension.
D6809
Key Part No. Description Qty.
D 6847 Salt Baffle Extension 1
D 6807 Discharge Baffle 1
D 6874 #14 x 1-1/2" TEK w/Neo Washer 2
Model # SP-8500
