SnowEx SP-8500 - Manual (Page 13)

© Trynex International 2010 1 — 13
Spinner Drive Assembly Parts Breakdown
Model # SP-8500
. y t Q n o it p i r c s e D . o N t r a P y e K
D 5293
D 5249
D 5349
D 6138
D 5248
D 4135
D 6563
D 5346
D 6333
D 6887
D 5343 D
D 5344
D 5342
T15038
D 6462
D 6833
T 15016
D 6452
D 6132
D 6462
D 6165
D 6833
D 6824
D 4289
D 6133
D 5347
D 6823
D 6854
5/16-18 x 1-1/8 Socket Head Cap Screw
5/16 Flat Washer
Spinner Shroud
5/16-18 Nylox Zinc
Plastic Handle
Hair Pin Clip
Drive Pin
Spinner Motor Cover
Long Rivet
Drive Motor
Left Hand Latch
8550 Spinner Drive Enclosure
Right Hand Latch
Shoulder Bolt
5/16-18 x 1-3/4 Hex Head Bolt
1/4-20 Nylox Stainless
3/8-16 x 1Serrated Flange Bolt
1/4-20 x 3/4 Serrated Flange Stainless
5/16-18 x 1-1/8
5/16 Flat Washer
Spinner Hub Weldment
1/4” Nylox Nut Zinc
5/16-18 x 1/2 Hex Head
Tubular Spinner Guard
Urethane Spinner
1/4-20 x 1 Serrated Flange
6
2
1
4
2
1
1
1
4
1
1
1
1
2
8
1
6
4
4
4
4
1
1
3
1
1
1
3
