Parts Breakdown
Model #SP-575
Motor Drive Assembly
Key
D 4116
1/2-13 Lock Nut
1/2-13 x 1-1/2” Hexbolt
Deflector Push Fastener
3/8-16 Serrated Flg Nut
3/8” Flat Washer
2-5/16 Hair Pin Clip
5/8” x 5-1/2” Hitch Pin
Flexible Draw Latch
Stainless Throat Liner
Deflector 20”
Throat Clamp
5/16-18 x 1-1/4” SS Panhead
2” Receiver Hitch
D 4120
D 6463
D 6584
D 4125
D 4135
D 4136
D 6105
D 6108
D 6110
D 6129
D 6137
D 6149
8
4
2
2
2
1
1
2
1
1
1
2
1
D 6239
575 Lid W/Latches
575 Hopper
575 Main Frame
5/16” Hex Nut
3/8” SS Washer
Latch Keeper
575 Top Screen
3/8-16 x 1” Ind Hwh Tcs
D 6240
D 6245
D 6168
D 6169
D 6198
D 6257
D 6452
1
1
1
2
2
2
1
4
Part No. Description Qty.
See Page 7-11
