Assembly Instructions

Model #SP-125 / US-100 (refer to diagram on page GR4-7)

Step 1: Attach hopper tube support (D 6712) to complete drive assembly using (4) 5/16"-18 x 1-3/4" hex bolt (D 6462)
and (4) 5/16" lock nut (D 6138). Use holes at bottom end of tube.

Step 2: Place spreader gate deck (D 6706) upside down on table.

Step 3: Assemble gate indicator/stop (D 6703) on stop slide with gate knob (D6302). Gate stop must be on the
inside of deck where it will stop the track.

Step 4: Insert (1) 5/16 bolt with hole (D 6308)

(D 6308) on bolt

through gate slide (D 6705) . Finger tighten (1) 5/16" locknut (D 6138)

Step 5: Take bulkhead cable fitting (D 6505) and screw it onto T-handle cable - 10' (D 6304) rubber coating.

Step 6: Place assembly through tab on gate deck. Tighten down with supplied washer and nuts. Note: There should be

a nut on either side of tab.

Step 7: Lower gate assembly over spinner shaft. Spinner shaft must go through 5/8" hole on deck.

Step 8: Fasten deck to hopper tube using (4) 5/16" hex bolts (D 6462) and (4) 5/16" locknuts (D 6138) NOTE: You

must first tighten bottom bolts, pull front of deck up, then tighten top set of bolts.

Step 9: Place hopper (D 6753) on deck. 5/8” hole must be used for spinner shaft.

Step 10: Finger tighten (2) 5/16 x 1" bolts (D 6166) through bottom of hopper.

Step 11: Place (4) flat washers (D 4318) over hex bolts (D6462). Place bolts through hopper back and in though tube
support. Tighten with (4) 5/16" locknuts.

Step 12: Tighten bolts in bottom of hopper.
Step 13: Place agitator (D 6405) on spinner shaft. Tighen to middle of flat with short allen key.

Step 14: Attach receiver mount (D 6485) to transmission weldment (D 6480) using (4) 1/2" hex bolts (D 4116) and (4) 1/2" lock

nuts (D 4120).

Gate Cable Installation

Step 1: Place unit on vehicle where it will be permanently used. Place hitch pin in hitch so unit does not move.

Step 2: Route T-handle to desired operating location. There cannot be any bends or sharp corners.

Step 3: Take T-handle out of sleeve. Take nuts and washer off of sleeve.

Step 4: Drill hole to mount T-handle. Screw (1) supplied nut and washer on cable after inserting through drilled hole.

Step 5: Close gate slide all the way.

Step 6: Re-insert cable handle and wire all the way. Aim through bolt with hole and tighten bolt.
