Alpine TDM-7546E - Manual (Page 32)

32
English
TAPE SECTION
Tape Speed ................................................................................................... 1-7/8 ips (4.8 cm/sec) ±0.7%
Wow & Flutter ................................................................................................................................... 0.06%
Tape Signal-to-Noise Ratio ................................................................................................................ 60 dB
Frequency Response
With Alpine Test Tape ....................................................................................... 30–20,000 Hz (±3 dB)
GENERAL
Power Requirement .................................................................................. 14.4 V DC (11–16 V allowable)
Maximum Power Output * .......................................................................................................................... 35 W
×
4
Continuous Power Output ** ......................................................................................................... 15 W
×
4
Output Voltage ............................................................................................................... 500 mV/10k ohms
Maximum Pre-Output Voltage .............................................................................................. 2 V/10k ohms
Bass ...................................................................................................................................... ±15 dB/30 Hz
Treble .................................................................................................................................. ±10 dB/10 kHz
Weight ........................................................................................................................... 1.4 kg (3 lbs. 1 oz)
Loudness Contour ............................................................................................................. 10 dB at 100 Hz
CHASSIS SIZE (W
×
H
×
D) .................................................. 178 mm (7")
×
50 mm (2")
×
152 mm (6")
NOSEPIECE SIZE (W
×
H
×
D) ........................... 170 mm (6-3/4")
×
46 mm (1-13/16")
×
18 mm (11/16")
Specifications
* Under maximum operating voltage and input
signal, into 4 ohms.
** Per EIA-517 Standard, 40 Hz to 20 kHz,
0.8% THD, at 14.4 V battery voltage.
Due to continuous product improvement,
specifications and design are subject to change
without notice.
