Wiring Instructions
Tractor
STEP 1
Mount the Control Module (F51038) in a location under the hood that is out of the way of moving parts and high-temperature components.
STEP 2
Route the Battery Harness (F50601) from the Battery to the Control Module. Secure with zip-ties. Connect the Harness to the Battery.
STEP 3
Route the Vehicle Harness (F50625) from the hitch area to the Control Module. Do not route near high-temperature or moving components.
Allow for the last 12-18 inches at the plug end to hang loose. Secure with zip-ties , working back toward the Control Module.
STEP 4
Route the Data Cable (F50578) to the seat from the Control Module. Secure with zip-ties as needed. Leave approximately three feet spare at
the end so the operator can hold the Control Pendant in his hand.
STEP 5
Plug the Data Cable into the Control Pendant (F50574).
NOTE
Do not expose the Control Pendant to extreme conditions for an extended period of time. Store the Control Pendant indoors.
To maintain the usefulness of the tractor in the off-season, and to prevent damage to the Vehicle Harness, Data Cable and Control Pendant;
remove the Vehicle Harness, Data Cable and Control Pendant in the off-season.
