Connect rear end rib – ShelterLogic 70423 8 x 8 x 8 Shed-in-a-Box User Manual
Page 6
05_70423_G3
Page 6
03032
01010
D
800938
Cross
Rail
Middle
Rib
800938
03032
01010
Cross
Rail
End Rib
D
10115
Cover
Rail
13202
01011
01010
F
End
Rib
10115
Cover
Rail
Cover
Rail
13201
Middle
Rib
01010
01011
01010
01011
4. connect reAr enD riB
e
F
A. Assemble 2 Side Cross Rails using parts as shown.
B. Assemble 1 Top Cross Rail using parts as shown.
C. Assemble 2 Cover Rails using parts as shown
D. Connect the 2 Side Cross Rails at the Shelterlock
®
3X (800938).
E. Connect the Top Cross Rail at the 3- and 4-Way Connectors as shown.
F. Place a Cover Rail at each leg and secure it with a Cover Clamp as shown. Slide the Cover Rails so they
are 8 inches up from the ground.
Only HAND-TIGHTEN these bolts!
A
D
D
e
e
A
B
c
F
B
Assemble Side Cross Rails
Assemble Top Cross Rail
800704
800704
801293
800704
10115
10115
01010
01010
Assemble Cover Rails
13345
13344
No Bolt at this connection
c
801277
03032
01010
801293
01010
800704
03032
e
F
