X-TATIC PRO 7
5. Getting started
5.1 Connecting the microphone to the headset
1. Insert the microphone’s 3.5 mm
stereo plug loosely into the headset’s
microphone connector so that the
indications on both the microphone
and the headset point towards each
other.
2. Press the microphone’s plug into
the headset’s jack completely; turn
the microphone to the front and into
the desired position.
5.2 Connecting the breakaway cable
1. Plug the G9 male connector (yellow arrow!) of the breakaway cable into the G9
female connector (yellow arrow!) of the X-Tatic PRO headset.
2. Connect the breakaway cable’s G9 male connector (white arrow!) to one of the
SCU’s G9 female sockets (silver indication!).
Important Note:
Ensure to plug the connectors with matching color indications (yellow arrow > yellow
arrow and white arrow > silver indication) else your cable/SCU might get damaged!
1
2

