X-TATIC PRO 13
8. Connecting to PC
1. Connect the X-Tatic PRO to the SCU by plugging the breakaway cable’s G9 male
connector (white arrow) to the SCU’s G9 female socket (silver indication).
2. Connect the optical cable (remove protective caps on both ends!) to the optical
audio output of your PC ‘s sound card and the SCU’s optical audio input (grey lid).
3. Toggle the audio input selector switch to “Optical”.
4. Connect the power adapter of the X-Tatic to a wall outlet and the SCU’s ISO
power jack.
5. Connect the USB microphone cable for PC to the SCU’s USB connector and the
respective USB connector of your PC.
6. Switch on the SCU and the PC.
7. Define your audio input settings as follows (the following screenshots are for
illustration only and may vary depending on your operating system and/or hard-
ware configuration):
1
2
3
4
5

