scorpio 1000/2000
10.2 Top panel
1. Dismantle the plastic cover from the case’s top by unscrewing
both attachment screws on the rear (fig. 21).
fig. 21
2. Slide the cover backwards and lift it from the case.
3. Place the fan to the respective fan bracket from the inside. Screw
the fan to the fan bracket from the outside (fig. 22).
fig. 22
4. Connect the fan’s power connector to the PSU or the mainboard.
Note:
While installing fans make sure that (cool) air is taken in on the
case’s front side/bottom and blown out on its back side/top. The
PC components with the highest heat development should be
placed directly within the airflow.
