Liquid system calibration, Orifice selection table, 10" spacing – Seed Hawk GRANULAR AND LIQUID TANKS 2008 User Manual
Page 45
LIQUID SYSTEM CALIBRATION
NOTE: Table data is based on a ground speed of 5 mph (8 kph)
System
Pressure
(psi)
4916 - 30
4916 - 49
Combined
10
5.7
14.6
20.3
20
7.4
22.2
29.6
30
9.1
27.2
36.3
40
10.5
31.4
41.9
50
11.7
35.1
46.8
60
13.5
40.2
53.7
System
Pressure
(psi)
4916 - 30
4916 - 49
Combined
10
5.1
13.3
18.4
20
6.8
17.5
24.3
30
8.4
21.5
29.9
40
9.6
24.7
34.3
50
10.7
27.7
38.4
60
12.2
31.8
44
NOTE:
Above charts are for reference only, pressures may
vary without affecting the application rate.
12" SPACING
(US gallons per acre)
ORIFICE SELECTION TABLE
Application rate for 10" spacing
(US gallons per acre)
Application rate for 12" spacing
10" SPACING
